PocketAdmin – Keystroke Injection Device


This is a keystroke injection device (also called badusb). It is similar to a well-known USB rubber ducky made by hak5, but has much extended functionality, lower price and is also completely open source. It looks and feels like an ordinary USB flash drive, but acts as a keyboard that types in a preprogrammed payload. This payload can do anything from configuring a network to installing a reverse shell, since the device can basically do whatever an admin can with a terminal, but taking only a few seconds. This makes it a very powerful tool for automating sysadmin tasks or use in penetration testing.

Here is quick summary of how PocketAdmin is different from USB rubber ducky (and many others):

  1. Made from inexpensive off-the-shelf parts, with not only open source firmware, but hardware design files as well. This allows the user to do substantial modifications to the design, as well as provides an option to build your own units.
  2. Has a built-in interpreter (compatible with existing ducky script) which takes text files directly, so you never have to install any encoder software and keep converting payload.txt to inject.bin.
  3. Can act as both keyboard and USB disk, allowing for better payloads; the memory chip is integrated, so there is no need to keep sticking SD card in/out of various devices while developing payloads.
  4. Has an OS detection mechanism, which allows you to store multiple payloads simultaneously and have the device automatically pick the correct payload to run.
  5. Extended set of commands for extra functionality, such as: without doing any firmware update the user can set which VID / PID values to use, configure how the device should show up
    (keyboard only / flash disk only / keyboard+disk), change keyboard layout, and many other things.


project is designed using KiCad 5.0.2

  • check KiCad pcb file for PCB manufacturing info
  • check KiCad sch file + BOM.txt for component info

Uses integrated full-speed (12Mbit/s) USB2.0 peripheral, with on-board 32MiB flash memory chip for data storage; only 24MiB are available for use due to overprovisioning reasons.

Measured speeds for MSD access : read 728 KiB/s, write 110-150 KiB/s, with higher write speeds being acheived for files smaller than 4MiB. While not very fast, it is enough for most badusb applications.

The pushbutton on the device is referred to as MSD-only button. Normally the payload is run whenever you plug the device into a PC. But if you press and hold this button while inserting the device, it prevents any keystrokes from being typed in and makes the device show up as a flash drive.

Fully assembled unit has dimensions of 59x18x9mm and weight of 8 grams. When opening up the case, be careful no to break the plastic studs near the USB connector and at the opposite (from USB) end of enclosure.

Hardware programmer device used in this project is ST-Link V2

For instructions on how to build and flash the device go check this video:


  • programming language used = C
  • flashing software used = openocd
  • IDE used = emacs text editor + Makefile

The firmware was developed on debian 9.7 system, using gcc-arm-none-eabi toolchain (compiler, linker, binutils) and it does use gcc specific extentions. it was successfully compiled and tested with arm-none-eabi-gcc version 7.3.1

depends on libgcc.a, which is included in this repository. linker script, startup code and openocd configuration files are included here as well.

Files usb_rodata.h, hid_rodata.h, msd_rodata.h are not really headers, but integral parts of usb.c, main.c, msd.c respectively. they are not intended to be included in any other files.

For your convenience, a pre-built binary firmware image is available in /extra/ directory. the name format is like this: firmware_RRNNN, where RR stands for board revision (11 = rev 1.1) , NNN stands for firmware version. For example, firmware_12003 means board revision 1.2, firmware version 3
